4.3. Legend for submenus and parameters
The purposes and characteristics of submenus and parameters are described and summarized in the following tables.
4.3.1. Submenu
1 2 3 4
Acronym Scrolling message Password Description
INFO INSTRUMENT STATUS Livello 1 Gives information on controller state and HW configuration
1. Acronym of submenu as it appears on controller
display.
2. Text of scrolling message as it appears on controller
display.
4.3.2. Parameter
8 9
6
5
7
1 2 3 4
Acronym Scrolling message Submenu Attributi
Out1 OUTPUT TYPE INFO R
RELAY = Relay output
DIGIT = Logic output 24 V
CONTS = Continuous output
The parameter specifies the type of output 1.
Unit of measurement: -
Options:
1. Acronym of parameter as it appears on controller
display.
2. Text of scrolling message as it appears on controller
display.
3. Submenu to which parameter belongs.
4. Attributes of parameter: R = readable, W = writable. If
only R, the operator or technician can read the parame-
ter value but cannot change it.
5. Description of use of parameter, including any warnings
or suggestions.
6. Unit of measurement of value managed by parameter.
The unit of measurement can be unique or depend
on other configuration choices, for example, the unit
of measurement of temperature, which can be set in
degrees Centigrade or Fahrenheit. Not all parameters
require the use of units of measurement.
7. Description of parameter values or information that can
be read or written, as appropriate.
8. Value that the parameter can have. Value can be two
types: discrete or pertaining to an interval of values,
typically numerical. For a discrete value, all possible
values are listed as they appear on the controller
display. For intervals of values, the minimum and maxi-
mum parameter values are shown.
9. Any additional description of value of individual
parameter.
3. Password needed to access submenu items.
4. Description of functions that manage submenu..
