1-Port Clear Channel DS3/E3 GPIM LEDs
The 1-Port Clear Channel DS3/E3 Gigabit-Backplane Physical Interface Module (GPIM)
has the LEDs described in Table 44 on page 79.
Table 44: 1-Port Clear Channel DS3/E3 GPIM LED States
DescriptionStateColorLED
GPIM is online and functioning
normally.
OnGreenSTATUS
GPIM is starting up, running
diagnostics, or shutting down.
OnYellow
GPIM has failed.OnRed
GPIM has no power and can be
removed safely.
Off
Loss of signal online.OnYellowLOS
Loopback is on.OnYellowLPBK
Port is receiving alarm indication
signal (AIS) alarm.
OnYellowAIS
Port is receiving remote defect
indication (RDI) alarm.
OnYellowRDI
There are no alarms or defects.OnGreenALARM
An alarm or a defect is present.OnRed
Out-of-frame (OOF) RX
multi-frame is not aligned.
OnYellowOOF
Related
Documentation
1-Port Clear Channel DS3/E3 GPIM Overview on page 75•
• 1-Port Clear Channel DS3/E3 GPIM Hardware Specifications on page 78
• 1-Port Clear Channel DS3/E3 GPIM Network Interface Specifications on page 24
• 1-Port Clear Channel DS3/E3 GPIM Supported Standards on page 80
• 1-Port Clear Channel DS3/E3 GPIM Key Features on page 77
• 1-Port Clear Channel DS3/E3 GPIM Components on page 76
• 1-Port Clear Channel DS3/E3 GPIM Supported Loopback Diagnostics on page 80
• 1-Port Clear Channel DS3/E3 GPIM Basic Configuration on page 221
79Copyright © 2015, Juniper Networks, Inc.
Chapter 11: 1-Port Clear Channel DS3/E3 GPIM
