Juniper SRX Series User Manual

24-Port Gigabit Ethernet XPIM Key Features
The 24-Port Gigabit Ethernet XPIM has the following key features:
•
24 triple-speed (10/100/1000 Mbps) Ethernet ports, double-high and double-wide
card
•
4 ports that can be configured to use SFPs
•
PoE support for all ports
•
PCI-Express interface for control and management
•
I2C interface for module monitor and identification
•
Maximum module power of 40.0 W without PoE
•
JTAG support for boundary scan test
Related
Documentation
24-Port Gigabit Ethernet XPIM Overview on page 109•
• 24-Port Gigabit Ethernet XPIM Hardware Specifications on page 113
• 24-Port Gigabit Ethernet XPIM LEDs on page 114
• 24-Port Gigabit Ethernet XPIM Components on page 110
• 24-Port Gigabit Ethernet XPIM Basic Configuration on page 233
24-Port Gigabit Ethernet XPIM Hardware Specifications
The 24-Port Gigabit Ethernet XPIM has the hardware specifications listed in
Table 62 on page 113.
Table 62: 24-Port Gigabit Ethernet XPIM Hardware Specifications
ValueDescription
1.58 in. H x 13.49 in. W x 8.5 in. L
(40.2 cm x 34.3 cm x 21.6 cm)
Dimensions (H x W x L)
2.79 lb (1.27 kg)Weight
24 RJ-45 and 4 small form-factor pluggable
(SFP) ports
NOTE: Ports 20 to 23 are shared so you can
use either the RJ-45 copper ports 20–23 with
10/100/1000 Mbps, or the SFP connector ports
20–23 for 1 Gigabit connectivity.
Connector types
113Copyright © 2015, Juniper Networks, Inc.
Chapter 16: 24-Port Gigabit Ethernet XPIM
