RS-232 DTE Cable Pinouts for the 8-Port Serial Gigabit-Backplane Physical Interface
Module
Table 99 on page 188 gives the RS-232 DTE cable pinouts for the 8-Port Serial
Gigabit-Backplane Physical Interface Modules.
Table 99: RS-232 DTE Cable Pinouts for the 8-Port Serial GPIM
DescriptionDirDB-25 (2) PinDB-25 (1) PinVHDCI-68 Pin
Shield Ground1T37
Send Data (A)O2T16
Receive Data (A)I3T41
Request to Send (A)O4T50
Clear to Send (A)I5T42
Data Mode (A)I6T45
Copyright © 2015, Juniper Networks, Inc.188
SRX Series Services Gateways for the Branch Physical Interface Modules Reference
