1-Port DOCSIS Mini-Physical Interface Module Network Interface Specifications
Table 16 on page 22 provides the network interface properties of the Data over Cable
System Interface Specifications Mini-Physical Interface Module (1-Port DOCSIS Mini-PIM).
Table 16: 1-Port DOCSIS Mini-PIM Network Interface Properties
UpstreamDownstreamSpecifications
Quadrature Phase Shift Keying (QPSK)
and 8, 16, 32, 64, 128 QAM
64 or 256 quadrature
amplitude modulation
(QAM)
Modulation
200 kHz, 400 kHz, 800 kHz, 1.6 MHz, 3.2
MHz, 6.4 MHz
6 MHz (US)Bandwidth
160, 320, 640, 1280, 2560, and 5120
ksym/s
64 QAM 5.057 Msym/s, 256
QAM 5.361 Msym/s
Symbol rate
A-TDMA +8 to +54 dBmV (32 QAM, 64
QAM); +8 to +55 dBmV (8 QAM, 16
QAM); +8 to +58 dBmV (QPSK);
S-CDMA +8 to +53 dBmV (all
modulations)
-15 to +15 dBmVOperating level range
75Ω (nominal)75Ω (nominal)Input impedance
5 to 42 MHz (US)108 to 1002 MHz (edge to
edge)
Frequency range
Up to 4 channelsUp to 4 channelsChannel bonding
Related
Documentation
1-Port DOCSIS Mini-Physical Interface Module Overview on page 51•
• 1-Port DOCSIS Mini-Physical Interface Module Key Features on page 52
• 1-Port DOCSIS Mini-Physical Interface Module Supported Standards on page 55
• 1-Port DOCSIS Mini-Physical Interface Module Hardware Specifications on page 53
• 1-Port DOCSIS Mini-Physical Interface Module Basic Configuration on page 211
Copyright © 2015, Juniper Networks, Inc.22
SRX Series Services Gateways for the Branch Physical Interface Modules Reference
