Juniper SRX Series User Manual

CHAPTER 23
Serial Mini-Physical Interface Module
Cable Specifications
•
1-Port Serial Mini-Physical Interface Module Interface Cables on page 143
•
EIA-530A DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 144
•
EIA-530A DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 146
•
RS-232 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 148
•
RS-232 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 149
•
RS-422/449 (EIA-449) DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 150
•
RS-422/449 (EIA-449) DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 152
•
V.35 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 154
•
V.35 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 155
•
X.21 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 157
•
X.21 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 158
1-Port Serial Mini-Physical Interface Module Interface Cables
Table 80 on page 143 lists the cables that you can order from Juniper Networks to connect
to a port on the synchronous 1-Port Serial Mini-Physical Interface Module (Mini-PIM).
The device to which you are connecting and the serial interface types determine which
type of cable you need.
Table 80: Juniper Networks Serial Cables
Connector
TypeLengthInterface TypeProduct Number
Female3.04 m (10 ft)EIA530 cable (DCE)JX-CBL-EIA530-DCE
143Copyright © 2015, Juniper Networks, Inc.
