1-Port Gigabit Ethernet SFP Mini-Physical Interface Module Hardware Specifications
Table 23 on page 35 gives the physical specifications of the 1-Port Gigabit Ethernet small
form-factor pluggable Mini-Physical Interface Module (SFP Mini-PIM).
Table 23: 1-Port Gigabit Ethernet SFP Mini-PIM Physical Specifications
ValueDescription
0.80 in. x 3.75 in. x 5.9 in.
(2.0 cm x 9.5 cm x 14.5 cm)
Dimensions (H x W x L)
2.96 oz (84 g)Weight
SFPConnector type
Mini-PIMForm factor
Related
Documentation
1-Port Gigabit Ethernet SFP Mini-Physical Interface Module Overview on page 33•
• 1-Port Gigabit Ethernet SFP Mini-Physical Interface Module Key Features on page 34
• 1-Port Gigabit Ethernet SFP Mini-Physical Interface Module Network Interface
Specifications on page 19
• 1-Port Gigabit Ethernet SFP Mini-Physical Interface Module Supported Modules on
page 36
• 1-Port Gigabit Ethernet SFP Mini-Physical Interface Module LEDs on page 35
• 1-Port Gigabit Ethernet SFP Mini-Physical Interface Module Basic Configuration on
page 205
1-Port Gigabit Ethernet SFP Mini-Physical Interface Module LEDs
The 1-Port Gigabit Ethernet small form-factor pluggable Mini-Physical Interface Module
(SFP Mini-PIM) has two LEDs located to the right of the socket. Table 24 on page 35
describes the LED states.
Table 24: 1-Port Gigabit Ethernet SFP Mini-PIM LED States
DescriptionStateColorLED
Port is onlineOnGreenLINK
Port is offlineOff
Port is receiving or sending dataBlinkingGreenACT
Port might be on but is not receiving or
sending data
Off
35Copyright © 2015, Juniper Networks, Inc.
Chapter 3: 1-Port Gigabit Ethernet SFP Mini-Physical Interface Module
