Table 45: 2-Port 10 Gigabit Ethernet XPIM Components (continued)
DescriptionLocationComponent
•
Copper ports support link
speeds of 10/100/1000
Mbps/10 G in full-duplex
and half-duplex modes.
•
Fiber ports support link
speeds of 1000 Mbps/10 G
in full-duplex mode.
NOTE: The 1 G fiber port
configuration is supported
starting with Junos OS
Release 10.2R2.
•
Copper ports (for 10 G) use
a CAT-6a or CAT-7 cable
connector.
•
Copper ports support
autonegotiation; whereas
fiber ports do not support
autonegotiation.
NOTE: The 10 G fiber port
does not support
autonegotiation.
•
All ports support flow
control and can be
configured in loopback
mode for testing purposes.
Middle of the XPIMTwo groups of ports labeled 0
and 1, where each group
contains 1 copper port and 1
fiber port.
NOTE: By default, all ports are
flow control enabled, and
support link speed of 10 G in
full-duplex mode.
The 10 G fiber port does not
support autonegotiation.
Use the fiber ports to connect
various SFP+ transceivers for
fiber cable connections. See
Table 46 on page 85 for
supported SFP+ transceivers.
Use the captive screws to hold
the XPIM in place.
One on each side of the XPIMCaptive screws
You can customize the Ethernet interface type by using different SFP+ transceivers.
Table 46 on page 85 shows the available SFP+ transceivers.
CAUTION: If you are having a problem running a Juniper Networks device
that is using a third-party optic or cable, the Juniper Networks Technical
Assistance Center (JTAC) can help you diagnose the source of the problem.
Your JTAC engineer might recommend that you check the third-party optic
or cable and potentially replace it with an equivalent Juniper Networks optic
or cable that is qualified for the device.
Table 46: 2-Port 10- Gigabit Ethernet XPIM SFP+ Transceivers
ConnectorInterface TypeProduct Number
LC10GBase-SR Ethernet optical
transceiver SFP, 26 m reach
SFPP-10GE-SR
85Copyright © 2015, Juniper Networks, Inc.
Chapter 12: 2-Port 10-Gigabit Ethernet XPIM
