8-Port Serial GPIM Basic Configuration
The 8-Port Serial Gigabit-Backplane Physical Interface Module (GPIM) is a network
interface card (NIC) that installs in the front slots of the SRX650 and SRX550 Services
Gateways to provide physical connections to a WAN. After you install the GPIM in the
services gateway, you configure a network interface on the GPIM.
NOTE: Only the SRX650 Services Gateway supports hot-swappable
functionality for GPIMs. The SRX550 Services Gateway does not support
hot-swappable functionality for GPIMs.
Before you begin to configure the GPIM:
•
Ensure that you have configured security zones on the services gateway.
•
Ensure that you have configured security policies on the services gateway.
NOTE: This topic shows a basic configuration that applies a security zone to
all protocols and a default policy set. You can also configure specific zone
settings and policies on the interface.
To configure the 8-Port Serial GPIM and configure a network interface on the GPIM:
1. Verify that the 8-Port Serial GPIM is installed in the services gateway:
user@host > show chassis hardware
The following sample output shows that FPC 3 PIC 0 is the GPIM:
Hardware inventory:
Item Version Part number Serial number Description
Chassis AJ2409AA0005 SRX650
Midplane REV 08 710-023875 AAAB4991
System IO REV 08 710-023209 AAAC3710 SRXSME System IO
Routing Engine RE-SRXSME-SRE6
FPC 0 FPC
PIC 0 4x GE Base PIC
FPC 3 REV 00 750-038290 AADB5216 FPC
PIC 0 8x Sync Serial gPIM
FPC 6 REV 11 750-023872 AAAV8510 FPC
PIC 0 24x GE POE gPIM
Power Supply 1 Rev 02 740-024283 TF00372 PS 645W AC
2. Verify that the PIC on the GPIM is online:
user@host> show chassis fpc pic-status
The following sample output shows that FPC 3 PIC 0 is online:
root@srx-650-b# run show chassis fpc pic-status
Slot 0 Online FPC
Copyright © 2015, Juniper Networks, Inc.230
SRX Series Services Gateways for the Branch Physical Interface Modules Reference
