Related
Documentation
EIA-449 DTE Cable Pinouts for 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 168
•
• EIA-449 DCE Cable Pinouts for 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 163
• EIA-530 DTE Cable Pinouts for the 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 175
• EIA-530 DCE Cable Pinouts for the 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 171
• EIA-530A DCE Cable Pinouts for 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 179
• RS-232 DTE Cable Pinouts for the 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 188
• RS-232 DCE Cable Pinouts for the 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 186
• V.35 DTE Cable Pinouts for the 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 194
• V.35 DCE Cable Pinouts for the 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 190
• X.21 DTE Cable Pinouts for the 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 199
• X.21 DCE Cable Pinouts for the 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 197
RS-232 DCE Cable Pinouts for the 8-Port Serial Gigabit-Backplane Physical Interface
Module
Table 98 on page 186 gives the RS-232 DCE cable pinouts for the 8-Port Serial
Gigabit-Backplane Physical Interface Modules.
Table 98: RS-232 DCE Cable Pinouts for the 8-Port Serial GPIM
DescriptionDirDB-25 (2) PinDB-25 (1) PinVHDCI-68 Pin
Shield Ground1T37
Receive Data (A)I2T41
Send Data (A)O3T16
Clear to Send (A)I4T42
Request to Send (A)O5T50
Terminal Ready (A)O6T49
Copyright © 2015, Juniper Networks, Inc.186
SRX Series Services Gateways for the Branch Physical Interface Modules Reference
