Juniper SRX Series User Manual

• V.35 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 155
• X.21 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 157
• X.21 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 158
• 1-Port Serial Mini-Physical Interface Module Overview on page 61
RS-232 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
Table 84 on page 149 gives the RS-232 DTE cable pinouts.
Table 84: RS-232 DTE Cable Pinouts for the 1-Port Serial Mini-PIM
Description
LFH-60
PairingDB-25 PinLFH-60 Pin
Frame Ground-115
Transmit Data-260
Receive Data-31
Request to Send-448
Clear to Send-537
Data Set Ready-69
Signal Ground-757
Data Carrier Detect-813
Transmit Clock-1556
Receive Clock-175
Local Loopback-1841
Data Terminal Ready-2033
Terminal Clock-2452
---22 to 21
---18 to 17
Related
Documentation
EIA-530A DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 144
•
149Copyright © 2015, Juniper Networks, Inc.
Chapter 23: Serial Mini-Physical Interface Module Cable Specifications
