NOTE: Only the SRX650 Services Gateway supports hot-swappable
functionality for GPIMs. The SRX550 Services Gateway does not support
hot-swappable functionality for GPIMs.
Figure 27 on page 110 shows the 24-Port Gigabit Ethernet XPIM, and Figure 28 on page 110
shows the 24-Port Gigabit Ethernet XPIM with PoE.
Figure 27: 24-Port Gigabit Ethernet XPIM
Figure 28: 24-Port Gigabit Ethernet XPIM with PoE
Related
Documentation
24-Port Gigabit Ethernet XPIM Key Features on page 113•
• 24-Port Gigabit Ethernet XPIM Hardware Specifications on page 113
• 24-Port Gigabit Ethernet XPIM LEDs on page 114
• 24-Port Gigabit Ethernet XPIM Components on page 110
• 24-Port Gigabit Ethernet XPIM Basic Configuration on page 233
• Installing a Double-High, Double-Wide Gigabit-Backplane Physical Interface Module
on the SRX Series Services Gateway on page 258
24-Port Gigabit Ethernet XPIM Components
The 24-Port Gigabit Ethernet XPIM contains the components listed in Table 60 on page 110.
Table 60: 24-Port Gigabit Ethernet XPIM Components
DescriptionLocationComponent
Use the XPIM
ONLINE/OFFLINE button to
gracefully shut down the XPIM.
Right side of the XPIMXPIM ONLINE/OFFLINE button
Only the SRX650 Services
Gateway supports
hot-swappable functionality
for GPIMs. The SRX550
Services Gateway does not
support hot-swappable
functionality for GPIMs.
Copyright © 2015, Juniper Networks, Inc.110
SRX Series Services Gateways for the Branch Physical Interface Modules Reference
