FPC 6 REV 10 750-023808 AAAJ9355 FPC
PIC 0 4x CT1E1 gPIM
FPC 7 REV 10 750-023808 AAAV0753 FPC
FPC 8 REV 09 750-023810 AAAC6572 FPC
PIC 0 1x CLR CH T3/E3
Power Supply 0 Rev 03 740-024283 UE05105 PS 645W AC
•
Verify the FPC status of the interface:
show chassis fpc
root@srx650r03> show chassis fpc
Temp CPU Utilization (%) Memory Utilization (%)
Slot State (C) Total Interrupt DRAM (MB) Heap Buffer
0 Online -------------------- CPU less FPC --------------------
1 Empty -------------------- Not Usable --------------------
2 Offline ---------- FPC configured offline ----------
3 Empty -------------------- Not Usable --------------------
4 Empty -------------------- Not Usable --------------------
5 Offline ---------- FPC configured offline ----------
6 Online 0 0 128 14 41
7 Offline ---------- FPC configured offline ----------
8 Online 0 0 128 14 41
•
Verify the PIC status:
show chassis fpc pic-status
root@srx650r03> show chassis fpc pic-status
Slot 0 Online FPC
PIC 0 Online 4x GE Base PIC
Slot 2 Offline FPC
Slot 5 Offline FPC
Slot 6 Online FPC
PIC 0 Online 4x CT1E1 gPIM
Slot 7 Offline FPC
Slot 8 Online FPC
PIC 0 Online 1x CLR CH T3/E3
•
Set the DS3/E3 port mode; for example, DS3 mode:
set chassis fpc <fpc no> pic 0 port 0 framing t3/e3
NOTE: By default, the PIC comes up in DS3 mode and the t3-x/y/z physical
interface is created. The port mode chosen for t3 is IFDP_T3, and the port
mode chosen for e3 is IFDP_E3.
•
Assign the port an IP address:
set interfaces t3-3/0/0 unit 0 family inet address interface address/destination prefix
•
Assign MTU values:
set interfaces t3-3/0/0 unit 0 family inet mtu mtu values
•
Enable/disable unframed DS3 mode; for example, unframed:
set interfaces t3-3/0/0 t3-options unframed
•
Set encapsulation:
Copyright © 2015, Juniper Networks, Inc.222
SRX Series Services Gateways for the Branch Physical Interface Modules Reference
