FX3U Series Programmable Controllers
User’s Manual - Hardwaer Edition
105
6 Examination of System Configuration
6.8 Number of Input/Output (Occupied) Points and Current Consumption
1
Introduction
2
Features and
Part Names
3
Product
Introduction
4
Specifications
5
Version and
Peripheral
Devices
6
System
Configuration
7
Input/Output
Nos., Unit Nos.
8
Installation
9
Preparation and
Power Supply
Wiring
10
Input Wiring
6.8.4 [D] Input/output powered extension units/blocks
1. Input/output powered extension units
2. Input/output extension blocks
−: No need to calculate
* Four inputs and four outputs are occupied as unused numbers.
No. Type
Input/output Output current (mA)
Number of input/
output points
[points]
Input/output
[points]
5V DC power
supply
24V DC service
power supply
FX
2N-32ER-ES/UL 32 16/16
690
250
FX
2N-32ET-ESS/UL 32 16/16
FX
2N-32ER 32 16/16
FX
2N-32ES 32 16/16
FX
2N-32ET 32 16/16
FX
2N-48ER-ES/UL 48 24/24
460
FX
2N-48ET-ESS/UL 48 24/24
FX
2N-48ER 48 24/24
FX
2N-48ES 48 24/24
FX
2N-48ET 48 24/24
FX
2N-48ER-DS 48 24/24
−
FX
2N-48ET-DSS 48 24/24
FX
2N-48ER-D 48 24/24
FX
2N-48ET-D 48 24/24
No. Type
Number of input/
output points
Current consumed (mA)
5V DC Internal 24V DC External 24V DC
Types for addition of input/output
FX
2N-8ER-ES/UL
16
*
− 62.5 0
FX
2N-8ER
16
*
− 62.5 0
Types for addition of input
FX
2N-8EX-ES/UL 8 − 50 0
FX
2N-8EX 8 − 50 0
FX
2N-8EX-UA1/UL 8 − 50 0
FX
2N-16EX-ES/UL 16 − 100 0
FX
2N-16EX 16 − 100 0
FX
2N-16EX-C 16 − 100 0
FX
2N-16EXL-C 16 − 100 0
Types for addition of output
FX
2N-8EYR-ES/UL 8 − 75 0
FX
2N-8EYT-ESS/UL 8 − 75 0
FX
2N-8EYR 8 − 75 0
FX
2N-8EYT 8 − 75 0
FX
2N-8EYT-H 8 − 75 0
FX
2N-16EYR-ES/UL 16 − 150 0
FX
2N-16EYT-ESS/UL 16 − 150 0
FX
2N-16EYR 16 − 150 0
FX
2N-16EYS 16 − 150 0
FX
2N-16EYT 16 − 150 0
FX
2N-16EYT-C 16 − 150 0
D
D1
D
D2
To Next Page
