Mitsubishi FX3U Series User Manual

FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
261
14 Test Operation, Adjustment, Maintenance and Troubleshooting
14.7 Troubleshooting
11
High-Speed Counters
12
Output Wiring
13
Wiring for Various Uses
14
Test Run, Maintenance, Troubleshooting
15
IInput/Output Powered Extension Units
16
Input/Output Extension Blocks
17
Extension Power Supply Unit
18
Other Extension Units and Options
19
Display Module
20
Terminal Block
14.7 Troubleshooting
→ For the procedures on running and stopping the PLC, refer to Section 14.2.
→ For the procedures on operating the display module, refer to Chapter 19.
→ For the procedures on operating peripheral devices, refer to the manuals for the peripheral devices.
→ For the phone numbers and addresses of Mitsubishi Electric System & Service Co., Ltd.,
refer to the service network at the end of this manual.
14.7.1 Output does not operate (main unit and input/output extension blocks)
1. Output does not turn on.
Stop the PLC, and forcibly turn the inoperable output on then off with a peripheral device or the display
module to check its operation.
Check for troubles with external wiring.
• When the output operates
The output may be turned off unintentionally in the program. Reexamine the program.
(Duplicate coil or RST instructions)
• When the output does not operate
Check the configuration of the connected devices and the connection of the extension cables.
If the configuration of the external wiring and connected devices and the connection of the extension
cables are acceptable, the output circuit may be damaged.
Consult your local Mitsubishi Electric distributer.
2. Output does not turn off.
Stop the PLC, and check that the output turns off.
Check for trouble with external wiring.
→ For the procedures on running and stopping the PLC, refer to Section 14.2.
• When the output turns off
The output may be turned on unintentionally in the program.
Check that there are no duplicate coils in the program.
• When the output does not turn off
The output circuit may be damaged. Consult your local Mitsubishi Electric distributer.
14.7.2 24V DC input does not operate (main unit and input/output extension blocks)
1. Input does not turn on.
Disconnect the external wiring and connect the S/S terminal and the 0V terminal or the 24V terminal.
Short-circuit the 0V terminal or 24V terminal not connected to the S/S terminal and the input terminal, then
check the input display LED or a peripheral device to confirm that the input turns on.
2. Input does not turn off.
Check for leakage current from input devices.
If the leakage current is 1.5mA or more, it is necessary to connect a bleeder resistance.
→ For details on the measures, refer to Subsection 10.2.3.
Measures
When input turns on
Check that the input device does not have a built-in diode or parallel resistance.
If so, refer to Subsection 10.2.3.
When input does not
turn on
Measure the voltage between the 0V terminal or 24V terminal not connected to the S/S
terminal and the input terminal with a tester to confirm that the voltage is 24V DC.
• Check the configuration of the external wiring and connected devices and the connection of
the extension cables.
