Mitsubishi FX3U Series User Manual

FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
381
19 FX3U-7DM (Display Module)
19.17 Cassette (Memory Cassette Transfers)
11
High-Speed Counters
12
Output Wiring
13
Wiring for Various Uses
14
Test Run, Maintenance, Troubleshooting
15
IInput/Output Powered Extension Units
16
Input/Output Extension Blocks
17
Extension Power Supply Unit
18
Other Extension Units and Options
19
Display Module
20
Terminal Block
19.17.2 Transfer from memory cassette to internal RAM (Cassette -> RAM)
1) At the menu screen, use the [+] / [-] buttons to move the cursor to
the "Cassette" item, then press [OK] to display the "memory
cassette transfer screen".
To cancel the operation and return to the "top screen (time
display)", press [ESC].
2) Use the [+] / [-] buttons to move the cursor to the "Cassette → RAM"
item, then press [OK] to display the screen shown to the right.
To cancel the operation and return to the "memory cassette transfer
screen", press [ESC].
3) Press [OK] to begin the transfer.
Or, press [ESC] to cancel the operation.
• Caution:
Do not turn the PLC power off or perform writing from the programming tool while a program is being
transferred by a "memory cassette transfer" menu operation, doing so may destroy the program and
disorder the PLC.
4) Press [OK] or [ESC] to return to the "memory cassette transfer screen".
• Result and measures to take:
- The transfer is not executed if a "PLC is running" message
appears.
In this case, set the PLC to the STOP state, then perform the step
3) operation described above.
- The transfer is not executed if a "Transfer failed" message
appears.
In this case, turn the power off, check the memory cassette
connection, then attempt the operation again from the first step.
- A "Transfer completed" message appears when the transfer is
completed.
When this message appears, press [OK] or [ESC] to display the
"memory cassette transfer screen".
5) Press [ESC] to display the "menu screen".
Button Operation Description
ESC
Cancels the operation and returns to the "memory
cassette transfer screen".
- Disabled
+ Disabled
OK Executes the transfer.
Mem r yo
 RAM
 RAM
RAM:
Cas e t tse
Cas e t tse
Cas e t tse
Cas e t tse
()
 RAMCas e t tse
Read
O
aC
K
nce

EC  S
Ex c tuee
l
()
 RAMCas e t tse
Read
Plea e awist...
PCLingsirunn
()
 RAMCas e t tse
Read
Tran f re
f
s
ai eld
()
 RAMCas e t tse
Read
Tran f re
c
s
om lpeetd
