20 FX-16/32E*-*-TB (Terminal Block)
20.1 Overview
11
High-Speed Counters
12
Output Wiring
13
Wiring for Various Uses
14
Test Run, Maintenance, Troubleshooting
15
IInput/Output Powered Extension Units
16
Input/Output Extension Blocks
17
Extension Power Supply Unit
18
Other Extension Units and Options
19
Display Module
20
Terminal Block
20.1 Overview
A terminal block is used to convert connector type input/output terminals into a terminal block.
Moreover, dedicated input and output terminal blocks (built-in element types) can be used to receive AC input
signals for conversion to relay / transistor / triac output types.
Optional cable or
user-fabricated cable
Terminal blockTerminal block
