FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
44
3 Introduction of Products (Compliant with Overseas Standards)
3.1 List of Products (to be Connected) and Interpretation of Model Names
2. Input/output cables
3. Input/output connector
3.1.11 [N] Remote I/O
For the remote I/O of CC-Link, CC-Link/LT and AS-i system, refer to the manual and catalog of each master.
3.1.12 [O] Power supply unit
 : Compliance with standard or self-declaration  : Not targeted − : Not applicable
→ For more information on CE, UL and cUL, refer to Page 15 or later.
Model name Function
FX-16E-500CAB-S 5m(16’4") Bulk wire
FX-16E-150CAB 1.5m(4’11")
Flat cable (with tube). Both ends are provided with 20-pin connectors.FX-16E-300CAB 3m(9’10")
FX-16E-500CAB 5m(16’4")
FX-16E-150CAB-R 1.5m(4’11")
Round multicore cable. Both ends are provided with 20-pin connectors.FX-16E-300CAB-R 3m(9’10")
FX-16E-500CAB-R 5m(16’4")
FX-A32E-150CAB 1.5m(4’11")
Flat cable (with tube). The end on the PLC side is provided with two 20-pin
connectors, and the end on the terminal block side is provided with a
exclusive connector. 1 common terminal for 32 input/output points
FX-A32E-300CAB 3m(9’10")
FX-A32E-500CAB 5m(16’4")
Model name Function
FX
2C-I/O-CON 10-piece set Input/output connector for flat cable
FX
2C-I/O-CON-S 5-piece set
Input/output connector for bulk wire for 0.3 mm
2
[AGW22]
FX
2C-I/O-CON-SA 5-piece set
Input/output connector for bulk wire for 0.5 mm
2
[AGW20]
Model name Description
Driving power
supply
CE
UL
cUL
Marine
EMC LVD
FX
2N-20PSU 24V DC power supply 100 to 240V AC  −
N
O
To Next Page
