16 FX2N-8/16E*-*(Input/Output Extension Blocks)
16.3 FX2N-8ER (24V DC Sink Input, Relay Output)
11
High-Speed Counters
12
Output Wiring
13
Wiring for Various Uses
14
Test Run, Maintenance, Troubleshooting
15
IInput/Output Powered Extension Units
16
Input/Output Extension Blocks
17
Extension Power Supply Unit
18
Other Extension Units and Options
19
Display Module
20
Terminal Block
16.3.3 External dimensions
IN
FX2N-8ER
POWER
0 1 23
3210
OUT
43(1.7")
9(0.36")
80(3.15")
(mounting hole pitch)
87(3.43")
90(3.55")
Unit:mm(inches)2-φ4.5 mounting holes
