FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
15 FX2N-32/48E*-* (Input/Output Powered Extension Units)
15.7 FX2N-32ES
3. Output specifications (triac output type)
15.7.2 External dimensions
FX2N-32ES
15.7.3 Terminal layout
FX2N-32ES
Item FX2N-32ES
Number of output points 16 points
Connection type Removable terminal block (M3 screw)
Output unit Triac output (SSR)
External power supply 85 to 242V AC
Output circuit insulation Insulation with photo-thyristor
Indication of output operation When photo-thyristor is driven, LED on panel is lit.
Max. load
Resistance
load
0.3A/point
The total load current per common terminal should be the following value.
• 4 output points/common terminal: 0.8 A or less
Inductive load 15 VA/100V AC, 30 VA/200V AC
Open circuit leakage current 1 mA/100V AC, 2 mA/200V AC
Min. load 0.4 VA/100V AC, 1.6 VA/200V AC
Response time
OFF→ON 1 ms or less
ON→OFF 10 ms or less
Output circuit diagram
Load
Fuse
External
power supply
Y
COM
U
A common number applies to the of [COM ].
72456
1
3
0
72456
1
3
0
OUT
IN
L
X1
X3 X5 X7
X6
X0
X2 X4 X6
24+
N
COM X4
X7
COM4COM2
Y4
Y5
Y6
Y7 COM3
Y0
Y1
Y2
Y3
COM1
Y0
Y1
Y2
Y3
Y4
Y5
Y6
Y7
X3
X2
X1
X0
X5
FX
2N
-32ES
POWER
72456
1
3
0
72456
1
3
0
TRIAC UNIT
150 (5.91")
140 (5.52") (mounting hole pitch)
80 (3.15")
(mounting hole pitch)
90 (3.55")
9 (0.36")
Unit : mm (inches)
87 (3.43")
2-φ4.5 mounting holes
The terminal block uses
M3 terminal screws.
X0
COM
24+NL X1
X2
X3
X4
X5
X6
X7
X0
X1
X2
X3
X4
X5
X6
X7
Y4Y2
Y3
COM2
Y1
Y0
COM1
Y5
Y6
Y7
Y0
Y1
Y2
Y3
Y4
Y5
Y6
Y7
COM3 COM4
