FX3U Series Programmable Controllers

User’s Manual - Hardware Edition

310

16 FX2N-8/16E*-*(Input/Output Extension Blocks)

16.8 FX2N-8EYR-ES/UL, FX2N-16EYR-ES/UL (Relay Output)

16.8.3 External dimensions

FX2N-8EYR-ES/UL

2N-16EYR-ES/UL

FX2N-8EYR-ES

POWER

7654

43(1.7")

87(3.43")

80(3.15")

(mounting hole pitch)

90(3.55")

Unit:mm (inches)

9(0.36")

2-φ4.5 mounting holes

87(3.43")

80(3.15")

(mounting hole pitch)

90(3.55")

Unit:mm (inches)

9(0.36")

40(1.58")

2-φ4.5 mounting holes
