FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
19 FX3U-7DM (Display Module)
19.17 Cassette (Memory Cassette Transfers)
19.17.1 Transfer from internal RAM to memory cassette (Cassette <- RAM)
1) At the menu screen, use the [+] / [-] buttons to move the cursor to
the "Cassette" item, then press [OK] to display the "memory
cassette transfer screen".
To cancel the operation and return to the "top screen (time
display)", press [ESC].
2) Use the [+] / [-] buttons to move the cursor to the "Cassette ← RAM"
item, then press [OK] to display the screen shown to the right.
To cancel the operation and return to the "memory cassette transfer
screen", press [ESC].
3) Press [OK] to begin the transfer.
Or, press [ESC] to cancel the operation.
• Caution:
Do not turn the PLC power off or perform writing from the programming tool while a program is being
transferred by a "memory cassette transfer" menu operation, as these actions could destroy the program,
causing incorrect operation of the PLC.
4) Press [OK] or [ESC] to return to the "memory cassette transfer screen".
• Result and measures to take:
- The transfer is not executed if a "PLC is running" message
appears.
In this case, set the PLC to the STOP state, then perform step 3)
described above.
- The transfer is not executed if a "Transfer failed" message
appears.
In this case, turn the power off, check the memory cassette
connection, then attempt the operation again from the first step.
- The transfer is not executed if a "Memory Cassette is write-
protected" message displays.
In this case, turn the power OFF, set the memory cassette
PROTECT switch to OFF, then attempt the operation again from
the first step.
- A "Transfer completed" message appears when the transfer is
completed.
When this message appears, press [OK] or [ESC] to display the
"Cassette screen".
5) Press [ESC] to display the "menu screen".
Button Operation Description
ESC
Cancels the operation and returns to the "memory
cassette transfer screen".
- Disabled
+ Disabled
OK Executes the transfer.
Mem r yo
 RAM
 RAM
RAM:
Cas e t tse
Cas e t tse
Cas e t tse
Cas e t tse
()
 RAMCas e t tse
Wr i et
O
aC
K
nce

EC  S
Ex c tuee
l
()
 RAMCas e t tse
Wr i et
Plea e awist...
PCLingsirunn
()
 RAMCas e t tse
Wr i et
Tran f re
f
s
ai eld
Memo y C
i
r
s
port
asse t e
w
t
ri et- cetde
s
()
 RAMCas e t tse
Wr i et
Tran f re
c
s
om lpeetd
