19.8 Monitor/Test Mode [User-Registered Devices]
Regarding user-registered devices at "Monitor/Test" menu, monitor and test operations can be performed for
a maximum of 4 data registers (16-bit/32-bit) specified by the system information.
→ Refer to Section 19.19 for the user-registered device setting procedure.
19.8.1 Monitor mode operation
1) At the menu screen, use the [+] and [-] buttons to move the cursor
to the "Monitor/Test" item, then press [OK] to display the "device
selection screen" shown to the right.
To cancel the operation and return to the "top screen (time
display)", press [ESC] at the menu screen
2) "Use the [+] and [-] buttons to move the cursor to the "User" item.
To cancel the operation and return to the "device selection screen",
press [ESC].
3) Press [OK] to display the data registers specified by the system
information.
The first time the power is turned on, the display begins with device
No.1 of the "user-registered devices". At subsequent power ONs,
the device which was being monitored at the previous operation is
displayed.
If a specified user-registered device has been changed, the newly
specified device is displayed.
To cancel the operation and return to the "device selection screen", press [ESC].
4) Use the [+] and [-] buttons to scroll the user-registered devices
screen.
To cancel the operation and return to the "device selection screen",
press [ESC].
Display Content
[1]
Device comments (registered at the PLC) are displayed together with the devices.
If no device comment has been registered, the device comment area is left blank.
[2]
Device included in the user-registered devices
[3]
Current value
Button Operation Description
ESC Returns to the "device selection screen".
-
Scrolls the user-registered devices.
(User-specified device 1 → user-specified device 4 → user-specified device 3 → user-specified
device 2 → user-specified device 1)
+
Scrolls the user-registered devices.
(User-specified device 1 → user-specified device 2 → user-specified device 3 → user-specified
device 4 → user-specified device 1)
OK Switches to the test mode when hold for 1 second or longer.
D(16b i
DD ( 3 2
T
C
t)
bit)
R(16b i
DR ( 3 2
t)
bit)
ER( 16b i t )
ER(32b i t )D
X
Y
M
S
Use r
D100
10
[1]
[2]
[3]
Ha l t t ime r
D103
0
D104
