20 June 2005 PM TABLE
2-1
Preventive
Maintenance
2. PREVENTIVE MAINTENANCE SCHEDULE
2.1 PM TABLE
NOTE: Amounts mentioned as the PM interval indicate the number of prints.
Symbol key: C: Clean, R: Replace, L: Lubricate, I: Inspect
B195/B198/B264/B265 EM 150K 300K 450K NOTE
SCANNER/OPTICS
Reflector C C C Optics cloth
1st Mirror C C C Optics cloth
2nd Mirror C C C Optics cloth
3rd Mirror C C C Optics cloth
Scanner Guide Rails
I I I
Do not use alcohol. Lubricate
if necessary.
Platen Sheet Cover
C I I I
Dry cloth or alcohol. Replace
platen sheet if required.
Exposure Glass C C C Dry cloth or alcohol
Toner Shield Glass C C C Optics cloth
APS Sensor C C C Dry cloth or alcohol
Exposure Glass (Sheet
through)
C C C
Dry cloth or alcohol
DRUM (OPC) AREA
OPC Drum R R R
Charge Roller R R R
Charge Roller Cleaning
Roller
R R R
Drum Cleaning Blade 1 R R R
Drum Cleaning Blade 2 R R R
Quenching Lamp C Dry cloth
Pick-off Pawls R R R
Spurs C C C Dry cloth or alcohol
ID Sensor
C C C
Perform SP3-001-2 after
blower brush cleaning.
Cleaning Entrance Seal
C C C
Blower brush. Replace if
required.
Side Seal I I I
To Next Page
