SP6-xxx: Peripherals
ADF Registration Adjust 6006*
Adjusts the side-to-side and leading edge registration for simplex and duplex
original feeding in ARDF mode. Press to toggle ±.
SP6006 5 sets the maximum setting allowed for rear edge erase.
6006 1* Side-to-side [–3 ~ +3 / 0.0 / 0.1 mm step]
6006 2* Leading Edge (Thin Original) [–30 ~ +30 / 0.0 / 0.17 mm step]
6006 3* Leading Edge (Duplex Front) [–42 ~ +42 / 0.0 / 0.12 mm step]
6006 4* Leading Edge (Duplex Rear) [–42 ~ +42 / 0.0 / 0.12 mm step]
6006 5* Rear Edge Erase [–20 ~ +20 / –3.0 / 0.5 mm step]
6007 ADF Input Check
6007 1 Group 1
6007 2 Group 2
6007 3 Group 3
Displays the signals received from sensors and
switches of the ARDF.( 5.2.5)
ADF Output Check 6008
Switches on each electrical component (ARDF motor, solenoid, etc.) of the ARDF
for testing. ( 5.2.6)
ADF Free Run 6009
Performs a free run with the ARDF for duplex and stamp testing. Input the number
for the item you want to check, and then press to start.
This is a general free run controlled from the copier. For more detailed free run
modes, see the ARDF manual.
6009 1 Duplex Mode OFF/ON
6009 2 Stamp Mode OFF/ON
ADF Stamp Position Adjustment [–7~+7 / 0 / 0.5 mm steps] 6010*
Adjusts the horizontal position of the stamp on the scanned originals.
Japan
Bit 0 1
7 DLT SEF 11"x15"
North America
Bit 0 1
6 DLT SEF 11" x 15"
5 LT LEF US Exec LEF
4 LT SEF 8"x10" SEF
3 LG SEF F4 SEF
Europe
Bit 0 1
2 DLT SEF 8-K SEF
1 LT SEF 16-K SEF
Original Size Decision Priority
0 LT LEF 16-K LEF
6016*
Determines which original sizes are detected when an original is detected that is
larger than the size assigned to the original size sensor. This provides an alternate
selection for detection, other than that assigned with SP5131.
