20 June 2005 SERVICE PROGRAM MODE TABLES
5-3
Service
Tables
5.2.3 SERVICE TABLES
SP1-xxx: Feed
Leading Edge Registration 1001*
Adjusts the printing leading edge registration using the trimming area pattern
(SP2-902-3, No.11).
[+9 ~ –9 / 3.0 / 0.1 mm]
Use to toggle between ± before entering the value. Specification: 3 ±2 mm
Side-to-Side Registration 1002*
Adjusts the printing side-to-side registration from the 3rd paper feed station using
the trimming area pattern (SP2-902-3, No.11).Tray3, Tray4 for Paper Feed Unit.
Use the key to toggle between + and – before entering the value. Specification:
2 ±1.5 mm
1002 1 Tray 1 [–9 ~ +9/ +3.0 mm / 0.1 mm step]
1002 2 Tray 2 [–9 ~ +9/ +3.0 mm / 0.1 mm step]
1002 3 Tray 3 [–9~ +9/ +2.0 mm / 0.1 mm/step]
1002 4 Tray 4 [–9~ +9/ +2.0 mm / 0.1 mm/step]
1002 5 From Duplex Unit [–9 ~ +9/ +0.0 mm / 0.1 mm/step]
1002 6 Bypass Feed [–9 ~ +9/ +3.0 mm / 0.1 mm/step]
1002 7 LCT (if present) [–9 ~ +9/ +1.5 mm / 0.1 mm/step]
Registration Buckle Adjustment 1003*
Adjusts the relay clutch timing at registration. Relay clutch timing determines the
amount of paper buckle at registration. (A “+” setting causes more buckling.)
1003 1 Trays 2,3,4 LCT
1003 2 Duplex
1003 3 Bypass
[–9 ~+9 / 0 /1 mm step]
1003 4 Tray 1 Feed [–9 ~+9 / 1 /1 mm step]
1003 5 Bypass Thick Paper [–9 ~+9 / -2 /1 mm step]
By-pass Feed Paper Size Display 1007*
Displays the paper width sensor data for the by-pass feed table.
Exit Junction Solenoid Start Timing 1012*
Adjusts the timing of the solenoids at the entrance and exit of the paper exit
section to accommodate the increased speed of the duplex unit.
This SP has been added to compensate for the increased operation speed of the
duplex unit for this machine. Increase the value if the leading edges are jamming.
Decrease the value if trailing edges are bending at the entrance
1012 1* Exit Entrance Junction
Solenoid
35 CPM: [200 ~ 450 ms / 370 ms / 10 ms]
45 CPM: [200 ~ 450 ms / 300 ms /10 ms]
1012 2* Exit Last Junction Solenoid 35 CPM: [200 ~ 450 ms / 370 ms / 10 ms]
45 CPM: [200 ~ 450 ms / 370 ms /10 ms]]
