20 June 2005 PAPER FEED
6-75
Detailed
Descriptions
6.11.7 PAPER SIZE DETECTION
The paper size switch includes four microswitches. Actuators behind the paper size
dial actuate the sensors.
Each paper size has its own actuator, with a unique combination of notches. To
determine the paper size, the CPU reads which switches the actuator has turned
off.
The CPU disables paper feed from a tray if the paper size cannot be detected. If
the paper size actuator is broken, or if there is no tray installed, the printer control
board recognizes that the paper tray is not installed.
When the paper size actuator is at the “✻” mark, the paper tray can be set up to
accommodate one of a wider range of paper sizes by using one of the user tools
on the machine’s operation panel.
Models Paper Size Switch
North America Europe/Asia 1 2 3 4
81/2" x 13" Portrait A3 Portrait ON ON OFF ON
A4 Landscape A4 Landscape ON ON ON ON
A4 Portrait A4 Portrait ON OFF ON ON
11" x 17" Portrait A5 Portrait OFF OFF ON ON
81/2" x 14" Portrait 8" x 13" Portrait ON OFF OFF OFF
81/2" x 11" Portrait 81/2" x 11" Portrait ON ON OFF OFF
81/2" x 11" Landscape 81/2" x 11" Landscape ON OFF ON OFF
✻ ✻
ON ON ON OFF
ON: Pushed OFF: Not Pushed
