20 June 2005 REAR COVERS
3-7
Replacement
Adjustment
3.7 REAR COVERS
3.7.1 REAR UPPER COVER
1. Rear upper cover [A] ( x2)
2. Controller cover [B] ( x2)
3.7.2 REAR LOWER COVER
1. Rear lower cover [A] ( x4)
B195R953.WMF
B195R905.WMF
[A]
[A]
[B]
