IMAGE FUSING AND PAPER EXIT 20 June 2005
6-96
Medium Jobs
After the machine prints a job of 30 to 99 continuous pages, the 1st Cleaning is
done twice. (15 sec. after the job ends the fusing/exit motor switches on for 15 sec.,
pauses for 15 sec. then switches on again for 15 sec.)
Large Jobs
After the machine prints a job of over 100 continuous pages, the 1st Cleaning is
done, there is a pause of 45 sec. then the 1st cleaning is done again.
Job End
Fusing Motor
15 s 15 s 15 s 15 s
B195D922.WMF
Job End
Fusing Motor
15 s 15 s 15 s45 s
B195D923.WMF
1st Cleaning x2
1st Cleaning + 45 sec. wait + 1st Cleaning
