PAPER FEED
20 June 2005
3-52
3.14.6
PAPER END/PAPER HEIGHT/RELAY SENSORS
1.
Remove the appropriate paper feed unit. (
3.14.4, 3.14.5)
2.
Paper height sensor [A] (
x1)
3.
Paper end sensor [B] (
x1).
4.
Relay sensor bracket [C] (
x1,
x1)
5.
Relay sensor [D]
B195R963.WMF
[A]
[B]
[C]
[D]
155
157
