DUPLEX UNIT 20 June 2005
6-80
6.13.2 DUPLEX DRIVE LAYOUT
1 Inverter roller 4 Transport motor
2 Inverter motor 5 Lower transport roller
3 Upper transport roller
B195D962.WMF
1
2
3
4
5
