20 June 2005 PAPER FEED
3-47
Replacement
Adjustment
3.14 PAPER FEED
3.14.1 PICK-UP, SEPARATION, AND FEED ROLLERS
1. Paper tray
2. Pick-up roller [A]
3. Feed roller [B] ( x 1)
4. Separation roller [C] ( x 1)
B195R956.WMF
[A]
[B]
[C]
