DUPLEX UNIT 20 June 2005
3-78
3.17.2 DUPLEX ENTRANCE SENSOR REPLACEMENT
1. Duplex unit cover (3.17.1)
2. Sensor holder [A] ( x1)
3. Entrance sensor [B] ( x1)
B195R805.WMF
[A]
[B]
