20 June 2005 IMAGE TRANSFER AND PAPER SEPARATION
6-83
Detailed
Descriptions
6.14 IMAGE TRANSFER AND PAPER SEPARATION
6.14.1 OVERVIEW
1 Transfer belt 6 OPC
2 Drive roller 7 Pick-off pawls
3 Transfer belt cleaning blade 8 ID sensor
4 Transfer roller 9 Contact lever
5 Idle roller 10 Transfer belt contact clutch/cam
B195D966.WMF
1
2
3
4
5
8
7
6
9
10
