20 June 2005 SPECIFICATIONS
SPEC-5
Spec.
3. OPTIONAL EQUIPMENT
ARDF (B714)
Original Size:
Normal Original Mode: A3 to B6, DLT to HLT
Duplex Original Mode: A3 to B5, DLT to HLT
Original Weight:
Normal Original Mode: 40 ~ 128 g/m
2
(11 ~ 34 lb.)
Duplex Original Mode: 52 ~ 105 g/m
2
(14 ~ 28 lb.)
Table Capacity: 80 sheets (80 g/m
2
, 20 lb.)
Original Standard Position: Rear left corner
Separation: Feed belt and separation roller
Original Transport: Roller transport
Original Feed Order: From the top original
Reproduction Range: 30 ~ 200% (Sub scan direction only)
Power Source: DC 24V, 5V from the copier
Power Consumption: Less than 60 W
Dimensions (W × D × H): 570 mm x 518 mm x 150 mm (22.4" x 20.4" x 5.9")
Weight: 12 kg
PAPER TRAY UNIT (B542)
Paper Size:
A5 SEF to A3 SEF
5
1/2" x 81/2" SEF to 11" x 17" SEF
Paper Weight: 64 g/m
2
~ 105 g/m
2
(20 lb. ~ 28 lb.)
Tray Capacity: 500 sheets (80 g/m
2
, 20 lb. )
Paper Feed System: FRR
Paper Height Detection: 4 steps (100%, 70%, 30%, Near end)
Power Source:
24 Vdc, 5 Vdc (from the copier)
120 Vac: 115 V version (from the copier)
220 ~ 240 Vac: 224/240 V version (from the copier)
Power Consumption: 50 W
Weight: Less than 25 kg (55.1 lb.)
Size (W x D x H): 540 mm x 600 mm x 270 mm (21.3" x 23.6" x 10.6")
