20 June 2005 DUPLEX UNIT
3-79
Replacement
Adjustment
3.17.3 DUPLEX EXIT SENSOR REPLACEMENT
1. Duplex unit (3.4)
2. Sensor bracket [A] ( x1)
3. Exit sensor [B] ( x1)
B195R806.WMF
[A]
[B]
