20 June 2005 TRANSFER UNIT
3-45
Replacement
Adjustment
3.13.2 TRANSFER BELT
1. Remove the transfer belt unit. ( 3.13.1)
2. Belt drive gear [A]
3. Set screws [B] ( x2)
4. Lay on a flat, clean surface and fold the unit to release the tension on the belt
[C].
5. Transfer belt [D]
NOTE:
1) Avoid touching the transfer belt surface.
2) Before installing the new transfer belt, clean all the rollers and shafts
with alcohol to prevent the belt from slipping.
3) When reinstalling the transfer belt, make sure that the belt is under the
pin [E].
4) To avoid damaging the transfer belt during installation, manually turn the
rollers and make sure that the new transfer belt is not running over the
edges of any of the rollers.
B195R954.WMF
[A]
[B]
[C]
[D]
[E]
[B]
