20 June 2005 TWO-TRAY FINISHER INSTALLATION (B545)
1-35
Installation
1.7 TWO-TRAY FINISHER INSTALLATION (B545)
1.7.1 ACCESSORY CHECK
Check the quantity and condition of the accessories in the box against the following
list:
Description Q’ty
1. Front Joint Bracket................................................................. 1
2. Rear Joint Bracket ................................................................. 1
3. Shift Tray ............................................................................... 2
4. Screw – M4 x 8 ...................................................................... 2
5. Screw – M4 x 12 .................................................................... 5
6. Ground Plate.......................................................................... 1
7. Installation Procedure ............................................................ 1
To Next Page
