Ruijie RG-WLAN Series User Manual

Configuration Guide Configuring 802.1X
 Create an account on the RADIUS server.
 Enable AAA on the NAS.
 Configure RADIUS parameters on the NAS.
 Enable 802.1X authentication on ports of the NAS.
 NAS configurations are as follows. For detailed configuration on the RADIUS server, see the
Configuring RADIUS.
ruijie# configure terminal
ruijie (config)# aaa new-model
ruijie (config)# radius-server host 192.168.32.120
ruijie (config)# radius-server key ruijie
ruijie (config)# wlansec 1
Ruijie(config-wlansec)# security rsn enable
Ruijie(config-wlansec)# security rsn ciphers aes enable
Ruijie(config-wlansec)# security rsn akm 802.1x enable
Verification
Check whether authentication is proper and network access behaviors change after authentication.
 The account is successfully created, such as username:tests-user,password:test.
 The user fails to ping 192.168.32.120 before authentication.
 After the user enters account information and click Authenticate on Ruijie Supplicant, the
authentication succeeds and the user can successfully ping 192.168.32.120.
 Information of the authenticated user is displayed.
ruijie# show dot1x summary
ID Username MAC Interface VLAN Auth-State Backend-State
Port-Status User-Type Time
--------- ---------- -------------- --------- ---- --------------- -------------
----------- --------- ------------------
16778217 ts-user 0023.aeaa.4286 wlan 1 2 Authenticated Idle Authed
static 0days 0h 0m 7s

Common Errors
 RADIUS parameters are incorrectly configured.
 The RADIUS server has a special access policy, for example, the RADIUS packets must carry certain attributes.
 The AAA authentication mode list is different from the 802.1X authentication mode list, causing authentication failure.
4.4.2 Configuring 802.1X Parameters
Configuration Effect
