Ruijie RG-WLAN Series User Manual

Configuration Guide Configuring IPv4/IPv6 REF
Configuration Example
 Configuring Load Balancing Based on Source and Destination IP Addresses
Scenario
Figure 9-2
A route prefix is associated with three next hops on router A, namely, link 1, link 2, and link 3.
Configuration
Steps
Configure load balancing based on IPv4 source and destination IP addresses on router A.
A
A#configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
A(config)#ip ref load-sharing original
Verification
A #show ip ref adjacency statistics
adjacency balance table statistic:
source-dest-address load-sharing
balance: 0
adjacency node table statistic:
total : 3
local : 1
glean : 0
forward: 0
discard: 0
mcast : 1
