FRONT BRAKE
4-8
CHAS
FRONT BRAKE
BRAKE P
AD
Order
Job name/Part name
Q.ty
Remarks
Brake pad removal
Remove the parts in order
.
1
Brake caliper screw
2
2
Brake caliper
1
3
Pad pin retainer
2
Refer to “BRAKE P
AD REPLACEMENT”
4
Pad pin
1
section.
5
Brake pad
2
6
Pad spring
2
Reverse the removal procedure for instal-
lation.
25 Nm (2.5 m
•
kg)
6
3
5
4
1
2
