FRONT BRAKE
4-16
CHAS
BRAKE CALIPER
Order Job name/Part name Q.ty Remarks
Caliper removal Remove the parts in order.
Brake fluid Drain.
1 Union bolt 1
2 Plain washer 2
3 Brake hose 1
Refer to “CALIPER INSTALLATION” sec-
4 Caliper support bolt 2
tion
5 Caliper assembly 1
Reverse the removal procedure for instal-
lation.
20 Nm (2.0 m
•
kg)
2
5
1
25 Nm (2.5 m
•
kg)
3
4
New
