Yamaha TT600RE 2004 User Manual

SPEC
MAINTENANCE SPECIFICATIONS
2-12
Item Standard Limit
Steering
Steering bearing type Taper roller bearing
Lock to lock angle (left) 45° •••
Lock to lock angle (right) 45° •••
Front suspension
Front fork travel 277 - 283 mm •••
Fork spring free length 530 mm •••
Spring rate (K1) 7.0 N/mm (0.71 kgf/mm) •••
Spring stroke (K1) 330 mm •••
Spring rate (K2) 11.2 N/mm (1.14 kgf/mm) •••
Optional spring available No
Recommended oil Liqui Moly Racing suspension oil SAE 7,5
Quantity 650 cc •••
Level 180 mm •••
< min - max > 170-190 mm (from upper edge of inner •••
tube, fully compressed without spring)
Rear suspension
Rear shock absorber assembly travel 83 mm
Spring free length 224 mm •••
Installed length 211 mm ± 1.5 mm
Spring rate (K) 80 N/mm (8.1 kgf/mm) •••
Optional spring available No
Swingarm
Free play limit (at the end of
the swingarm)-radial ••• 1.0 mm
Free play limit (at the end of
the swingarm)-axial 0.4 - 0.7 mm •••
Front wheel
Wheel type Spoke wheel
Rim size 21 x 1.85
Rim material Aluminium
Max. radial wheel runout 1.0 mm •••
Max. lateral wheel runout 0.5 mm •••
Rear wheel
Wheel type Spoke wheel
Rim size 18 x MT2.50
Rim material Aluminium
Max. radial wheel runout 1.0 mm •••
Max. lateral wheel runout 0.5 mm •••
CHASSIS

Yamaha TT600RE 2004 Specifications

General

Brand	Yamaha
Model	TT600RE 2004
Category	Motorcycle
Language	English
