ELECTRICAL STARTING SYSTEM
7-24
ELEC
DIAGNOSTICS
THE STARTER FAILS TO WORK
Procedure
Inspect:
(1) Fuse
(2) Battery
(3) Starting motor
(4) Starter relay
(5) Main switch
(6) Engine stop switch
(7) Sidestand switch
(8) Neutral switch
(9) Clutch switch
(10) Starter switch
(11) Harness connections
NOTE:
Before starting inspections, remove the following parts:
1. Seat
2. Rear cowling
3. Fuel tank
4. Cowling (headlight)
•
To check for defects use the following special tools.
Pocket tester:
P/N. 90890-03112
1. Fuse.
•
Remove fuse.
•
Connect the pocket tester (Ω x 1) to the
fuse.
•
Check the fuse for continuity.
Refer to “CHECKING THE FUSES” in
Chapter 3.
2. Battery.
•
Check the condition of the battery.
Refer to “CHECKING AND CHARGING
THE BATTERY” in Chapter 3.
Min. open-circuit voltage:
12.8 V or more at 20°C (68°F)
CONTINUITY
DISCONTINUTY
Replace the fuse.
INCORRECT
•
Clean the battery terminals.
•
Recharge or replace the battery.
Refer to “BATTERY INSPECTION” in
Chapter 3.
*
CORRECT
