CHAS
DRIVE CHAIN, DRIVE SPROCKET
AND REAR WHEEL SPROCKET
4-85
3. Tighten:
•
Rear wheel sprocket fastening bolts
Rear wheel sprocket fastening bolts:
48 Nm (4.8 mkg)
Nut (drive sprocket):
110 Nm (11.0 mkg)
Nut (swingarm pivot shaft):
90 Nm (9.0 mkg)
Nut (frame-relay arm):
60 Nm (6.0 mkg)
▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲
DRIVE CHAIN INSTALLATION
Perform “REMOVAL” operations in reverse order.
Pay special attention to the following points.
1. Install:
•
Drive chain
•
Swingarm
2. Install:
•
Rear wheel
Refer to “REAR WHEEL INSTALLATION”
section.
3. Install:
•
Drive sprocket
WARNING
Always use a new lock washer.
NOTE:
•
Tighten the drive sprocket nut with the rear
brake pulled.
•
After tightening the nut, bend the tab on the
lock washer once more over the faces of the
nut.
4. Adjust:
•
Drive chain slack
Refer to “DRIVE CHAIN SLACK ADJUST-
MENT” section in CHAPTER 3.
Drive chain slack:
30 ~ 40 mm
To Next Page
