ELEC
LIGHT SYSTEM
7-43
DIAGNOSTICS
THE HIGH BEAM LIGHT, PARKING INDICATOR LIGHT, REAR LIGHT, FRONT PARKING
LIGHT AND/OR INSTRUMENT LIGHTS FAIL TO TURN ON.
Procedure
Inspect:
1. Fuse
2. Battery
3. Main switch
4. Dipped/high beam light and dimmer switch
5. Relay assy
6. Harness connections (full system of connec-
tions)
NOTE:
•
Before starting inspections, remove the following parts:
1. Seat
2. Rear cowling
3. Cowling (headlight)
4. Tail light cover
•
To check for defects use the following special tools.
Pocket tester:
P/N. 90890-03112
1. Fuse
•
Check the fuse for continuity.
Refer to “CHECKING THE FUSES” in
Chapter 3.
•
Is the fuse OK?
YES
2. Battery
•
Check the condition of the battery.
Refer to “CHECKING AND CHARGING
THE BATTERY” in Chapter 3.
Min. open-circuit voltage:
12.8 V or more at 20°C (68°F)
•
Is the battery OK?
NO
Replace the fuse.
NO
•
Clean the battery terminals.
•
Recharge or replace the battery.
YES
*
To Next Page
