LUBRlCATlON POINTS AND LUBRICANT TYPE
LUBRlCATlON POINTS AND LUBRICANT TYPES
ENGINE
Lubrication points (part name) Lubricant type
Oil seal edges (completely)
Bearing retainer
Rod pins
Rod (big end)
Piston and piston rings
Hub (weight drive sprocket)
Piston pin
Valve stim and guide
Oil seal (valve stim end)
Rocker shaft and rocker arm
Cam and bearing (camshaft)
Rotor and rotor housing (oil pump)
Push rod (clutch)
Primary driven gear and main shaft
Sliding gear (transmission)
Idle gear (transmission)
Shift forks and bar
Shift cam and bearing (gearshift cam)
Shift shaft
Rod housing coupled surfaces Bonding agent (rapid seal adhesive)
®
Yamaha bond No. 1215
®
Coupled surfaces (cylinder head and cylinder head cover) Bonding agent (rapid seal adhesive)
®
Yamaha bond No. 1215
®
