2-21
SPEC
LUBRlCA
TlON POINTS AND LUBRICANT TYPE
CHASSIS
Lubrication points (part name)
Lubricant type
Gear unit (tachometer)
Oil seal edges (completely)
Wheel axle (front and rear wheels)
Rear wheel hub and clutch
Bearings brasses (rear arm) and bearing push cover
Front footrest
Pivot points (brake pedal and shift pedal)
Bearings (steering head)
Pivot points (brake lever and clutch lever)
Clutch cable end
Pivot points (sidestand)
Grease nipples (rear arm-front axle)
41
43
