BRAKE CIRCUIT BLEEDING
3-34
INSP
ADJ
1
1
B
BRAKE CIRCUIT BLEEDING
WARNING
If the brake lever or brake pedal has a soft or
slack feel, this means that there is air in the
brake system. It should be bled away before
using the motorcycle. Air in the system seri-
ously affects the effectiveness of braking and
may cause loss of control of the motorcycle.
In all cases, bleed the brake system if:
•
The system has been disassembled.
•
A brake hose has been loosened or
removed.
•
The brake fluid in the tank is at a very low
level.
•
Brake operation is faulty.
Air bleeding procedures:
a. Top up the level of the fluid in the tank to max-
imum.
b. Install the diaphragm. Be careful not to spill
fluid or let it overflow from the tank.
c. Connect the clear plastic hose (1) to the
caliper bleeder screw.
[A] Front
[B] Rear
d. Place the other end of the hose in a container.
e. Slowly pull the brake lever or press the brake
pedal several times.
f. Pull the brake lever right in or press the pedal
right down and hold in position.
g. Loosen the bleeder screw and allow the lever
or pedal to travel slowly towards its limit.
h. Tighten the bleeder screw when the lever or
pedal limit has been reached, then release the
lever or pedal.
Bleeder screw:
14 Nm (1.4 mkg)
i. Repeat operations (e) to (h) until all the air
bubbles have disappeared from the clear
plastic hose (1).
