ELECTRICAL ST
ARTING SYSTEM
7-30
ELEC
ST
ARTER MOTOR
(1) Brushes
(2) Armature
(3) Stator
(4) O-Ring
BRUSH LENGHT LIMIT
5 mm (0.20 in)
COMMUT
A
TOR WEAR LIMIT
:
27 mm (1.06 in)
MICA UNDERCUT
:
0.7 mm (0.027 in)
ARMA
TURE COIL RESIST
ANCE:
0.03 ~ 0.04
Ω
at 20°C (68°F)
